Induction Machines Handbook: Steady State Modeling and Performance (3rd Edition)

$19.99

Download Induction Machines Handbook: Steady State Modeling and Performance (3rd Edition) written by Ion Boldea in PDF format. This book is under the category Electronics and bearing the isbn/isbn13 number 367466120/9780367466121. You may reffer the table below for additional details of the book.

SKU: 339a18def989 Category: Tag:

Specifications

book-author

Ion Boldea

publisher

CRC Press; 3rd edition

file-type

PDF

pages

443 pages

language

English

asin

B0899WN69W

isbn10

367466120

isbn13

9780367466121


Book Description

Induction Machines Handbook: Steady State Modeling and Performance; 3rd Edition; (PDF) provides a comprehensive treatment of steady-state induction machines (IM); the generally used electric motor (generator) in somewhat constant or variable speed drives; always lower energy consumption and higher productivity in fundamentally all industries; from home appliances; through robotics to wind energy conversion and e-transport.

Chapter 1 provides a detailed introduction from basic principles to topological classifications and most important applications and power ranges from tens of W to tens of MW. Then separate Chapters 2 and 4 deal in detail with particular issues; like

  • Losses
  • Thermal modeling
  • Electric windings and their MMF
  • Starting and speed control methods
  • Skin and on-load saturation effects
  • Magnetization curve and inductance
  • Leakage inductances and resistances
  • Single-phase induction machine basic
  • Magnetic; electric; and insulation materials
  • Steady-state equivalent circuit and performance
  • Field harmonics; parasitic torques; radial forces; noise
  • Single-phase induction motors: steady-state modeling and performance

Fully updated and revised to reflect the last decade’s progress in the field; this third edition adds new sections; like

  • Closed-slot IM saturation
  • Equivalent circuits for BDFIM
  • Rotor leakage reactance saturation
  • Control principles for doubly-fed IM
  • PM-assisted split-phase cage-rotor IM’s steady-state
  • The brushless doubly-fed induction machine (BDFIM)
  • Multiphase and multilayer tooth-wound coil windings
  • The origin of electromagnetic vibration by practical experience
  • Magnetic saturation effects on current and torque versus slip curves

The promise of renewable (wind and hydro) energy through cage-rotor and doubly-fed variable speed generators e-transport propulsion and i-home appliances makes this edition a state-of-the-art tool; conceived with several case studies and timely for both academia and industry.

NOTE: The product only includes the ebook; Induction Machines Handbook: Steady State Modeling and Performance; 3e in PDF. No access codes are included.



Additional information

book-author

Ion Boldea

publisher

CRC Press; 3rd edition

file-type

PDF

pages

443 pages

language

English

asin

B0899WN69W

isbn10

367466120

isbn13

9780367466121

Table of contents


Table of contents :
Cover
Half Title
Series Page
Title Page
Copyright Page
Dedication
Table of Contents
Preface
Author
Chapter 1 Induction Machine Transients
1.1 Introduction
1.2 The Phase-Coordinate Model
1.3 The Complex Variable Model
1.4 Steady State by the Complex Variable Model
1.5 Equivalent Circuits for Drives
1.6 Electrical Transients with Flux Linkages as Variables
1.7 Including Magnetic Saturation in the Space-Phasor Model
1.8 Saturation and Core Loss Inclusion into the State-Space Model
1.9 Reduced-Order Models
1.9.1 Neglecting Stator Transients
1.9.2 Considering Leakage Saturation
1.9.3 Large Machines: Torsional Torque
1.10 The Sudden Short Circuit at Terminals
1.11 Most Severe Transients (So Far)
1.12 The abc–d-q Model for PWM Inverter-Fed IMs
1.12.1 Fault Conditions
1.13 First-Order Models of IMs for Steady-State Stability in Power Systems
1.14 Multimachine Transients
1.15 Subsynchronous Resonance (SSR)
1.16 The M/N[sub(r)] Actual Winding Modelling for Transients
1.17 Multiphase Induction Machines Models for Transients
1.17.1 The Six-Phase Machine
1.17.2 The Five-Phase Machine
1.18 Doubly Fed Induction Machine Models for Transients
1.19 Cage-Rotor Synchronized Reluctance Motors
1.20 Cage Rotor PM Synchronous Motors
1.21 Summary
References
Chapter 2 Single-Phase IM Transients
2.1 Introduction
2.2 The d-q Model Performance in Stator Coordinates
2.3 Starting Transients
2.4 The Multiple-Reference Model for Transients
2.5 Including the Space Harmonics
2.6 Summary
References
Chapter 3 Super-High-Frequency Models and Behaviour of IMs
3.1 Introduction
3.2 Three High-Frequency Operation Impedances
3.3 The Differential Impedance
3.4 Neutral and Common Mode Impedance Models
3.5 The Super-High-Frequency Distributed Equivalent Circuit
3.6 Bearing Currents Caused by PWM Inverters
3.7 Ways to Reduce PWM Inverter Bearing Currents
3.8 Summary
References
Chapter 4 Motor Specifications and Design Principles
4.1 Introduction
4.2 Typical Load Shaft Torque/Speed Envelopes
4.3 Derating due to Voltage Time Harmonics
4.4 Voltage and Frequency Variation
4.5 Specifying Induction Motors for Constant V and f
4.6 Matching IMs to Variable Speed/Torque Loads
4.7 Design Factors
4.7.1 Costs
4.7.2 Material Limitations
4.7.3 Standard Specicatfiions
4.7.4 Special Factors
